UV300F Under Vehicle Inspection System , Vehicle Security System Weather proof

Under vehicle surveillance system mainly detect a variety of vehicles at the bottom, can quickly and accurately identify hiding in the car at the bottom of contraband goods and illegal immigration, smuggling of persons, it is more faster and more accurate than the traditional vehicle inspection mirror, and greatly improving vehicle safety inspection speed and accuracy, reduce investment in human resources.

Features:

• Auto digital line scan, high-resolution undercarriage imaging.
• High automation, easy to be used.
• Applicable to variety of vehicles, wide vision.
• Test will be completed during the vehicle maneuvers without stopping, adapted to different speed.
• Undercarriage image can be stored, retrieved, searched or compared with other images.
• A variety of image processing methods: enlarge, stretching and cutting.
• Multi entrance management model, management, and statistics of entering and exiting vehicles.
• Flexible detection process can be made on site to satisfy the needs of various work conditions.
• Option of automatic number plate recognition system available, associative storage of various vehicle information and undercarriage images.
• Image monitoring, video recording for different scenario.

Advantage of UVSS:

• No need to park vehicle, can bear speed below 30km/h
• Whole image display ion monitor, can zoom, playback, sign in the images.
• Operator can zoom and save image

Main Technical Indexes:

Embedded Under Vehicle Imaging Equipment:

1. Camera: Sensor: line scans CCD, Resolution: 2048, Power Supply: 24VDC, 5A

2. Illumination: LED, Power Supply: 24VDC, 150W

3. Size: 1200mm x 350mm

4. Operating Temperature Range: -20 ℃ to +70 ℃

Controller:

1. Input: 2 channels induction coil
2. Output: 1 Channel switch type 24VDC
3. Communication port: RS485, Ethernet (Optional)
4. Operating Temperature: -20℃ to 55℃

System Host:

1. CPU: Intel Centurion Duo or higher, Memory: 2G, Hard Disk: 500G

2. Display: 22” LCD, can choose a vice display to show the image independently (optional)

3. Scene Video Record: 4 channel, Compression algorithm of scene video: H264
