vehicle image scanner, control equipment and environmental adaptability
1. Scan mode: full auto, non external trigger condition scan mode
2. The maximum of scan rate: 18 kHz
3. The detection speed: 1-60km/h, advise ≤ 30km/h;
4. Field of view: 170 degrees
5. Scanner data line: 10 m; (customizable length)
6. Auxiliary lighting: 160W
7. Lighting components: two single sealed LED surface light source; life: 50000h
8. The bottom image scanner: using a unique open wide design of field of vehicle image acquisition technology
9.Load capacity:>15T
10. Waterproof level: IP68 meet all day work
11. Scanning device weight: 28KG
12.Scanning device volume :450 x 400 x 88mm
13. Communication interface: RJ45
14. Storage temperature;-40°~75°
15. Operating temperature: -10° ~+60°
16.Operating power : 110-240V AC,50-60HZ

System host server and monitor:
1. Monitor: 22 bits real colors
2. CPU: INTEL Quad core processor
3. Motherboard: special board
4. Memory: DDR3, greater than 2GB
5. HD: 500G high speed hard drive
6. Graphics: 192BIT, DDR3 independent graphics card
7. Appearance: aluminum alloy composite material
8. Operation power: AC220V 50/60Hz
9. Operation electrity: 3A
10 Data transmission cable length: 10M

License plate recognition system (limited domestic)
1. The module of standard 1 license plate recognition can be extended to 2 or more matching;
2. The single character recognition accuracy rate: ≥ 99%;
3. Average recognition time: <20m/s
4.Entire brand recognition accuracy: ≥95%
5 Horizontal tilt angle of license plate image: -10 ~ +10 degree;
6. Character recognition accuracy (except Chinese characters): ≥ 93%
7.Noise:>48db
