DC24v Automation Under Vehicle Inspection System Uvss Integrated
With Anpr
Features:
l Auto digital line scan, high-resolution undercarriage imaging.
l High automation, easy to be used.
l Applicable to variety of vehicles, wide vision.
l Test will be completed during the vehicle maneuvers without
stopping, adapted to different speed.
l Undercarriage image can be stored, retrieved, searched or compared
with other images.
l A variety of image processing methods: enlarge, stretching and
cutting.
l Multi entrance management model, management, and statistics of
entering and exiting vehicles.
l Flexible detection process can be made on site to satisfy the needs
of various work conditions.
l Option of automatic number plate recognition system available,
associative storage of various vehicle information and
undercarriage images.
l Image monitoring, video recording for different scenario.
Embedded Screening Part
| Camera: Sensor: | line scans CCD |
| Resolution: | 5000*2048 pixels |
| Power Supply: | 24VDC, 3A |
| Illumination: | LED |
| Power Supply: | 24VDC,150W |
| Size: | 1200mm x 350mm |
| Operating Temperature Range: | -20 degree to +70 degree |
System Host
| Brand: | Grantech (SYM76941VGGA) |
| CPU: | Intel(R)Celeron(R)CPU |
| E3400 2.6GHz 2.59 GHz |
| Memory: | 2G( optional 4G) |
| Graphics: | 512M |
| Hard Disk: | SATA2 Hard Disk 500G |
| Dual LAN | At least one Intel Gigabit |
| USB2.0 | Up to 2 pieces |
| Monitor: | 22 inch LCD,resolution up to 1920*1080 |
| Scene Video Record: | 4 channel, Compression |
| algorithm of scene video: H264 |
Controller
Input: | 2 channels induction coil |
| Output: | 1 Channel switch type 12VDC |
| Communication port: | RS485, Ethernet(Optional) |
| Operating Temperature: | -10℃ to 55℃ |
Features
1 Multi entrance management model, management, and statistics of
entering and exiting vehicles
2 High automation, easy to be used
3 Auto digital line scan, high-resolution undercarriage imaging.
4 Applicable to variety of vehicles, wide vision.
5 Test will be completed during the vehicle maneuvers without
stopping, adapted to different speed.
6 Undercarriage image can be stored, retrieved, searched or
compared with other images.
7 Avariety of image processing methods: enlarge, stretching and
cutting.
8 (Optional)ALPR-Automatic License Plate Recognition and RFID
technology associative storage of various vehicle information and
undercarriage images.
