Wide range of products for your market we produced: |
Description | Model NO. | Application |
X-ray baggage Scanner | SF5030/SF5636/SF6040/SF6550 SF8065/SF10080/SF100100 | Airport,custom,Hotel |
Walk Through Metal Detector | UB500,UB600,UB700,UM600,UZ800 | Border,exhibition,government |
Under Vehicle Surveillance System | UV300M, UV300F | Prision, Jail,big events, games |
Explosive Trace Detector | MD3003B1, V160 | Military base |
| Camera: Sensor: | line scans CCD |
| Resolution: | 5000*2048 pixels |
| Power Supply: | 24VDC, 3A |
| Illumination: | LED |
| Power Supply: | 24VDC,150W |
| Size: | 1200mm x 350mm |
| Operating Temperature Range: | -20 degree to +70 degree |
System Host :
| Brand: | Grantech (SYM76941VGGA) |
| CPU: | Intel(R)Celeron(R) , E3400 2.6GHz 2.59 GHz |
| Memory: | 2G( optional 4G) |
| Graphics: | 512M |
| Hard Disk: | SATA2 Hard Disk 500G |
| Dual LAN | At least one Intel Gigabit |
| USB2.0 | Up to 2 pieces |
| Monitor: | 22 inch LCD,resolution up to 1920*1080 |
| Scene Video Record: | 4 channel, Compression |
| algorithm of scene video: | H264 |
Controller :
| Input: | 2 channels induction coil |
| Output: | 1 Channel switch type 12VDC |
| Communication port: | RS485, Ethernet(Optional) |
| Operating Temperature: | -10℃ to 55℃ |
Features:
* Auto digital line scan, high-resolution undercarriage imaging.
* High automation, easy to be used.
* Applicable to variety of vehicles, wide vision.
* Test will be completed during the vehicle maneuvers without
stopping, adapted to different speed.
* Undercarriage image can be stored, retrieved, searched or
compared with other images.
* Flexible detection process can be made on site to satisfy the
needs of various work conditions.
* Image monitoring, video recording for different scenario.
Application:
1. Airport, prison, custom and other government department
2. Large public parking spot entrance and exit
3. Events, exhibition
4. Military, prison and other important checkpoints
Optional :
1. ALPR-Automatic License Plate Recognition
2. RFID technology: associative storage of various vehicle
information and undercarriage images.
Functions:
1 .Under vehicle surveillance system mainly adopt to inspect the
beneath part of a variety of vehicles.
2. It can quickly and accurately identify threats/ contraband/
smuggling of persons hiding at the bottom.
3. UVSS greatly improved vehicle safety inspection speed and
accuracy, reduce investment in human resources.
