    Small Size Dual Energy X Ray Luggage Scanner Machine Security Inspection Sf5030c For Park

    Ask Lasest Price
    Brand Name : Uniqscan
    Model Number : SF5030C
    Certification : CE ISO
    Price : 6000- 18000 usd/unit
    Payment Terms : T/T
    Supply Ability : 50000pcs per month
    Delivery Time : in one week
    • Product Details
    • Company Profile

    Small Size Dual Energy X Ray Luggage Scanner Machine Security Inspection Sf5030c For Park


    Small Size Dual Energy X Ray Luggage Scanner Machine Security Inspection Sf5030c For Park

    General Specifications

    General Specifications

    Tunnel Size : 530 (W) ×350 (H) mm

    Conveyor Speed: 0.22m/s

    Conveyor Max Load: 150 kg

    Single inspection dosage: <1.01μGy

    Leakage radiation: <0.06µGy/h

    Wire Resolution: 40AWG

    Steel Penetration: 40mm

    Film Safety: For ISO 1600

    X-RAY GENERATOR

    Orientation: Upward

    Tube Current: 0.4-1.25mA(adjustable)

    Anode Voltage: 80-160KV(adjustable)

    Angle: 80°

    Generator cooling/working periods:

    Sealed oil bath with forced air/100%


    1) Display: High-resolution 19 inch color LCD display


    2) Color quality: 24-Bit real colors based on materials

    3) Edge enhancement: Object contour edge is more distinct

    4) Super image enhancement: Image detail is more distinct

    5) High penetration display: Increase the contrast of bright area in image to make the area that is easy to penetrate appear more clearly

    6) Low penetration display: Increase the contrast of dark area in image to make the area that is difficult to penetrate appear more clearly.

    7) Magnifier: Partial magnifying function

    8) Brightening/dimming: Increase/Decrease brightness of image

    9) Image recurrence: Display the previous twenty images and process any one of them

    10) Image restoration: Restore image to initial status

    11) Image storage: Real-time store any image and process it in operation status

    12) Multi-energy: High/low energy: Switch from high energy to low energy

    13) Color material identification: Organic objects in orange, inorganic objects in blue, mixture in green. Assist to detect drug and explosive powder


    Packaging
    Size
    Package Dim. with wooden case L*W*H (mm)
    2250*970*1350
    Weight
    600KG
    Packaging Details
    The normal package is wooden box.

    If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
