SF5030C small size X ray baggage scanners for hand bags security check in hotel

General Specifications:
<sup><sub>1. Tunnel Size : 500 (W) ×300 (H) mm
2. Conveyor Speed: 0.22m/s
3. Conveyor Max Load: 150 kg
4. Single inspection dosage: <1.32μGy
5. Leakage radiation: <0.06µGy/h
6. Wire Resolution: 40AWG
7. Steel Penetration: 38mm
8. Film Safety: For ISO 1600</sub></sup>

X-RAY GENERATOR:
1. Orientation: Upward
2. Tube Current: 0.4-1.2mA(adjustable)
3. Anode Voltage: 100-160KV(adjustable)
4. Angle: 80°
5. Generator cooling/working periods:Sealed oil bath with forced air/100%

OPERATING ENVIRONMENT:
1. Storage Temperature: -20oC to 60oC
2. Operating Temperature: 0oC to 45oC
3. Relative Humidity:20 to 95% non-condensing
4. System Power: 220 VAC (±10%) 50±3HZ
5. Power wastage: 1.0 KW (Max)
6. Noise<65DB

X-RAY Sensor: L-shaped array detector, 24bit , Dual energy

Image Performance System:
1. Display: High-resolution 19 inch color LCD display
2. Color quality: 24-Bit real colors based on materials
3. Edge enhancement: Object contour edge is more distinct
4. Super image enhancement: Image detail is more distinct
5. High penetration display: Increase the contrast of bright area in image to make the area that is easy to penetrate appear more clearly
6. Low penetration display: Increase the contrast of dark area in image to make the area that is difficult to penetrate appear more clearly.
7. Magnifier: Partial magnifying function
8. Brightening/dimming: Increase/Decrease brightness of image
9. Image recurrence: Display the previous twenty images and process any one of them
10. Image restoration: Restore image to initial status
11. Image storage: Real-time store any image and process it in operation status

Multi-energy: High/low energy: Switch from high energy to low energy

Color material identification: Organic objects in orange, inorganic objects in blue, mixture in green
Assist to detect drug and explosive powder

Special features:
1. Network interface: Capable of connecting to LAN, and support multi-terminal check for baggage at same time
2. Safety ray: Ray is transmitted under automatic control, avoiding the error
3. One-key shutdown control: Just rotate the key to shut down the machine; it is safety, easy and convenient
4. Eagle eye: Capable of expediently observing the magnifying area
5. Self-diagnosis function: Give message automatically if malfunction for prompt maintenance

Application:

Shenzhen Unisec Technology Co., Ltd is a professional security scanner equipment manufacturer, specialized the development and research in the x-ray imagine tehnology, metal detection technology, explosive detection, liquid detection and relative security services.

OUR BRIEF

We always adhere to customer-centric, the principles of honesty and trustworthiness, is committed to efforts to improve and continuous innovate its own responsibility .

OUR TECHNOLOGY
We owns all of the intellectual property rights (IPR) to its core technologies ,and have a experience engineer team with senior x-ray detection exports, signal and imagine processing specialist , excellent technical support and maintance engineers.

OUR SERVICES
We strictly in accordance with the ISO9001 quality standard requirements from production research , manufacture, marketing to after services, established a complete quality management and assurance system . Also we take effective marketing management protection measures to control the products qulity ,working efficiency and service attitudes ,to ensure all our clients have our best quality products and best services.
