xray parcel scanner/xray baggage scanner/xray luggage scanner
Company information
ABOUT US
Shenzhen Unisec Technology Co., Ltd is a professional security
scanner equipment manufacturer, specialized the development and
research in the x-ray imagine tehnology, metal detection
technology, explosive detection, liquid detection and relative
security services.
OUR BRIEF
We always adhere to customer-centric, the principles of honesty and
trustworthiness, is committed to efforts to improve and continuous
innovate its own responsibility .
OUR TECHNOLOGY
We owns all of the intellectual property rights (IPR) to its core
technologies ,and have a experience engineer team with senior x-ray
detection exports, signal and imagine processing specialist ,
excellent technical support and maintance engineers.
OUR SERVICES
We strictly in accordance with the ISO9001 quality standard
requirements from production research , manufacture, marketing to
after services, established a complete quality management and assurance system .
Also we take effective marketing management protection measures to
control the products qulity ,working efficiency and service
attitudes ,to ensure all our clients have our best quality products
and best services.
General Specifications
Tunnel Size : 600(W) ×400(H) mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 150 kg
Single inspection dosage: <1.01μGy
Leakage radiation: <0.06µGy/h
Wire Resolution: 40AWG
Steel Penetration: 40mm
Film Safety: For ISO 1600
X-RAY GENERATOR
Orientation: Upward
Tube Current: 0.4-1.25mA(adjustable)
Anode Voltage: 80-160KV(adjustable)
Angle: 80°
Generator cooling/working periods:
Sealed oil bath with forced air/100%
OPERATING ENVIRONMENT
Storage Temperature: -20oC to 60oC
Operating Temperature: 0oC to 45oC
Relative Humidity:
20 to 95% non-condensing
System Power: 220 VAC (±10%) 50±3HZ
Power wastage: 1.0 KW (Max)
Noise<55DB
X-RAY Sensor: L-shaped array detector, 24bit
Image Performance System:
Display: High-resolution 19 inch color LCD display
Edge enhancement: Object contour edge is more distinct
Super image enhancement: Image detail is more distinct
High penetration display: Increase the contrast of bright area in
image to make the area that is easy to penetrate appear more
clearly
Low penetration display: Increase the contrast of dark area in
image to make the area that is difficult to penetrate appear more
clearly.
Magnifier: Partial magnifying function
Brightening/dimming: Increase/Decrease brightness of image
Image recurrence: Display the previous twenty images and process
any one of them
Image restoration: Restore image to initial status
Image storage: Real-time store any image and process it in
operation status
Multi-energy: High/low energy: Switch from high energy to low energy
Color material identification: Organic objects in orange, inorganic objects in blue, mixture in
green
Assist to detect drug and explosive powder
Special features:
Network interface: Capable of connecting to LAN, and support
multi-terminal check for baggage at same time
Safety ray: Ray is transmitted under automatic control, avoiding
the error
One-key shutdown control: Just rotate the key to shut down the
machine; it is safety, easy and convenient
Eagle eye: Capable of expediently observing the magnifying area
Self-diagnosis function: Give message automatically if malfunction
for prompt maintenance
Color quality: 24-Bit real colors based on materials
Certificate
Scanned images
Production
Our service
FAQ
