Portable UVIS Under Vehicle Inspection System With Capture Camera for Drive Face
---------------------------------------------------------------------------------------------------------------

Technical parameters

• Vertical resolution of the image: 5000*2048 pixels
• Check the width viewing angle: < 4 meters
• Speed of vehicle: < 30km/h with ALPR(Automatic Licence Plate Recognition)
• Speed of vehicle: < 70km/h without ALPR(Automatic Licence Plate Recognition)
• Effective Field of View(FOV): Less than 170°
• Auxiliary light: 100W
• Weight capacity: <20T
• Water-proof grade: IP66
• Scanning device weight: 24KG
• Scanning device volume: 450mm× 400mm× 88mm
• Communication interface: RS232/RS422
• Operating Temperature: -10degree to 55degree
• Storage temperature: -40degree to +75degree
• Operating voltage: 110-240V AC, 50-60Hz

---------------------------------------------------------------------------------------------------------------

System Host

• Brand: Grantech (UFO6377H-SP1-953)
• CPU: Intel® Core(TM) 2 Duo CPUP8600@2.4GHz or higher
• Memory: 2G( optional 4G)
• Graphics: Inter(R) Gen 5.0 Integrated Graphics Engine
• Hard Disk: SATA2 Hard Disk 500G
• Dual LAN (At least one Intel Gigabit)
• USB2.0 (Up to 4 pieces)
• Monitor: 22inch LCD,
• Resolution up to 1920*1080

---------------------------------------------------------------------------------------------------------------

Functions:
1 Under vehicle surveillance system mainly adopt to inspect the beneath part of a variety of vehicles.
2 It can quickly and accurately identify threats/ contraband/ smuggling of persons hiding at the bottom.
3 UVSS greatly improved vehicle safety inspection speed and accuracy, reduce investment in human resources.

Remarks:

• Carry one year quality waranty
• Technology support all life free of charge
