1. Standard Specification:

2. Parameters:

1. Standard product features:

1) It has fault self-test and alarm prompt function, which is convenient for users to maintain and use;

2) The operating state of the programmable device through the built-in small push panel on the main control board;

3) Anti-pinch and anti-collision function, when the resistance is blocked during the swing arm reset, the motor will automatically stop working within the specified time. After the default delay, it will be reset again (until reset), and the force is very small (≤2Kg );

4) Anti-shock function, the swing arm is automatically locked when no open signal is received;

5) The swing arm is synchronously adjustable (for double swing);

6) With automatic reset function, the system will automatically cancel the user's permission for the passage when the switch is not open within the specified time;

7) Freely adjustable normally open or normally closed to meet the requirements of different venues;

8) It can be connected with a variety of card reading devices to receive relay switch signals;

9) One-way and two-way pendulum function, which can control the entry and exit of personnel in one direction or two directions;

10) Remote control and management can be realized directly through the management computer;

11) Delay automatic reset, the system defaults to 10 seconds (adjustable) automatic reset after turning on;

12) The power-off swing arm is automatically opened and automatically closed when it is powered, which meets the fire protection requirements.

3. Optional features:

1) Sound and light alarm functions, including illegal intrusion alarm, anti-pinch alarm, etc.;

2) Counting function;

3) Infrared reset function;

4) The chassis is lengthened, the swing arm is lengthened, and so on.

4. Main structure and configuration

SUS304 standard case

Stainless steel swing arm

Turnstile control PCB

Direction indicator board

Power supply

Motor

Movement and transmission part 1 set

Infrared sensor 3 pairs
